Painted surface for enhanced corrosion resistance
Single-acting cylinder with spring return for easy, quick operation
Lightweight and compact low-profile design, ideal for confined spaces
| Handle Type (S) | Model | Ton (t) | Stroke (mm) | Pressure Area (cm) | Oil Volume (cm) | Closed Height A(mm) | Extended Height (mm) | Outer Dia. D(mm) | Inner Dia. E(mm) | Ram Dia. F(mm) | Weight (kg) |
| RCS101 | 10 | 38 | 14.5 | 55 | 88 | 126 | 69 | 42.9 | 38 | 4.1 | |
| RCS201 | 20 | 45 | 28.7 | 129 | 98 | 143 | 92 | 60.5 | 50 | 5 | |
| RCS302 | 30 | 61 | 42.1 | 261 | 117 | 179 | 101 | 73.2 | 65 | 6.8 | |
| ● | RCS502 | 50 | 60 | 62.1 | 373 | 122 | 182 | 124 | 88.9 | 70 | 10.9 |
| ● | RCS1002 | 100 | 57 | 126.7 | 722 | 141 | 198 | 165 | 127 | 90 | 22.7 |
