Carbon steel base with automated welding for stable quality
Alloy steel piston rod with chrome plating, durable and rust-resistant
Suitable for leveling lifting machinery and working in confined spaces
| Model | Top LoadU (t) | Claw LoadF (t) | Stroke(mm) | Body HeightA (mm) | Extended HeightB (mm) | Piston Rod Dia.J (mm) | Base SizeLxW (mm) | Claw HeightK (mm) | Claw Block SizeLxW (mm) | Weight(kg) |
| SL-05S | 5 | 2.5 | 117 | 228 | 345 | 29 | 130x125 | 16 | 69x45 | 8.5 |
| SL-10S | 10 | 5 | 147 | 282 | 429 | 42 | 235x186 | 22 | 98x53 | 20 |
| SL-20S | 20 | 10 | 152 | 310 | 462 | 55 | 251x241 | 25 | 123x60 | 31.5 |
| SL-30S | 30 | 15 | 155 | 330 | 485 | 62 | 273x262 | 28 | 149x60 | 44 |
| SL-50S | 50 | 25 | 155 | 370 | 528 | 85 | 280x340 | 40 | 190x75 | 88.5 |
